Embedded LED flat panel soft light
Embedded LED flat panel soft light
Color temperature: 3200K, 5600K optional.
Control panel: LCD display+four buttons
Beam angle: 120 degrees Dimming: 0-100% linear dimming.
Technical parameter
GX-8054
Embedded LED flat panel soft light
Input voltage: AC100-240V, 50/60Hz
Power: 160W
Light source: 630 high-definition LED arrays
Color rendering index: Ra>95
Light source lifespan: 100000 hours
Color temperature: 3200K, 5600K optional.
Control panel: LCD display+four buttons
Beam angle: 120 degrees Dimming: 0-100% linear dimming.
Heat dissipation method: No fan for natural heat dissipation.
Channel mode: 1CH/2CH.
Control mode: DMX512 control/manual control.
Protection level: IP20
Working temperature: -25 ℃~+45 ℃
Shell material: aluminum alloy
Opening size: 495 * 300mm
Product size: 500 * 270 * 110mm
Carton size: 550 * 340 * 115mm
Net weight/gross weight: 5.5KG/6.5KG
Embedded LED flat panel soft light
Input voltage: AC100-240V, 50/60Hz
Power: 160W
Light source: 630 high-definition LED arrays
Color rendering index: Ra>95
Light source lifespan: 100000 hours
Color temperature: 3200K, 5600K optional.
Control panel: LCD display+four buttons
Beam angle: 120 degrees Dimming: 0-100% linear dimming.
Heat dissipation method: No fan for natural heat dissipation.
Channel mode: 1CH/2CH.
Control mode: DMX512 control/manual control.
Protection level: IP20
Working temperature: -25 ℃~+45 ℃
Shell material: aluminum alloy
Opening size: 495 * 300mm
Product size: 500 * 270 * 110mm
Carton size: 550 * 340 * 115mm
Net weight/gross weight: 5.5KG/6.5KG
