optical system
Light source: Philips SMSD Silver380WEC
Life: 2000h
Color system
Multi point color temperature variation (8000K/3200K)
Color tray 1: A color tray, each consisting of 13 color chips and white light;
Color Plate 2: Colorful Plate Effect.
Pattern disc: 13 pattern effects.
Effect wheel: One rotatable 16 prism and one honeycomb mirror (24 prism effect)
Dimming: 0-100% electronic dimming;
Strobe: Supports mechanical and adjustable strobe effects, and supports strobe macro functions;
Lens group optical system, electric focusing, linearly adjustable beam angle of 0-2.3 °;
Adopting a photoelectric reset system, it can automatically retrieve and reset in case of accidental misoperation;
Shake head parameters
Horizontal 540 °, resolution 8Bit/16Bit;
Vertical 270 °, resolution 8Bit/16Bit;
Control mode: International standard DMX512 signal, 16 channels supporting RDM bidirectional transmission, self-propelled mode, master-slave mode intelligent heat dissipation: adopting wind direction drainage and temperature intelligent monitoring technology, automatically driving cooling fans in different parts of the lamp according to the temperature of different positions, effectively cooling the lamp components
Menu display: 2.0 LCD display screen
source
100-240V~50/60Hz
electronic ballast
Input power: 600W
Power factor: PF ≥ 0.98
Size and weight
Product size: 570 * 320 * 220mm
Net weight of the product: 21KG
Product gross weight: 19KG
Protection level
IP 20
